Okuma heavy-duty, Big Bore CNC turning center- Crown 762S-BB -

Description

Information belown is typical not necesserally the listed machine.
Make Okuma
Model No. Crown 762S-BB
Country of Origin: Japan
Serial # 0847
OKUMA CROWN 762S-BB Equipped With:
Okuma OSP-700L CNC Control
IGF – Interactive Graphic Function
Microcentric CB65-D Hydraulic Collet Chuck
12-Station Turret
Hydraulic Tailstock with Quill
Floppy Drive
Slant Bed Rigid Box Way Machine
Chip Conveyor
Coolant System.
Automatic Lubrication system
Foot Operated Control for Chuck & Tailstock
Coolant Tank
Comes with Chuck, Chip Conveyor, Levelling pads
OKUMA CROWN 762S-BB Specifications:
Max Turning Diameter: 10.63″
Max Turning Length: 19.68″
Max Bar Capacity: 3.05″
Swing Over Bed: 21.65″
Distance Between Centers: 22.29″
X Axis Travel: 7.28″
Z Axis Travel: 20.47″
Rapid Traverse X Axis: 590 IPM
Rapid Traverse Z Axis: 787 IPM
Spindle Nose: A2-8
Spindle Bore: 3.15″
Spindle Speed: 65-3500 RPM
Spindle Motor: 22 HP
Turret Capacity: 12 Stations
Turret Index Time: 1 Second
Tailstock Quill Dia.: 3.54″
Tailstock Quill Stroke: 4.72″
Tailstock Taper: MT-5
General:
Power Source: AC 220 V, Three Phase, 60 Hz
Overall Dimensions: 104″ x 76″ x 72″ High
Overall Dimensions: 142″ x 76″ x 80″ High W/Chip Conveyor
Weight : 9900
